Factory prices facade outline lighting 50mm width 24W led linear light 1M outdoor PC cover dmx 512 led light linear bar

VISUAL ANGLE

DIMENSIONAL DRAWING

INSTALLATION DIAGRAM

COLOR AVAILABLE

PRODUCT SELECTION

Model	Wattage Voltage Brand/Model LED quantity colors					Pixel
GSMY-12CW	12W	DC24V	EPISTAR 5050	48	2200-6500k	Single color
GSMY-24CW	24W	DC24V	EPISTAR 5050	2*48	2200-6500k	Single color
GSMY-36CW	36W	DC24V	OSRAM 2835	2*96	2200-6500k	Single color

PRODUCT SELECT-ON

Can be customized color:

golden yellow, emerald green, amber yellow, lake blue light. Golden Buddha light and other colors

Model	Wattage Voltage Brand/Model LED quantity colors					Pixel
GSMY-12CW512	12W	DC24V	EPISTAR 5050	48	Grayscale change	8
:GSMY-24CW512	24W	DC24V	EPISTAR 5050	2*48	Grayscale change	8

Can be customized color:

golden yellow, emerald green, amber yellow, lake blue light, Golden Buddha light and other colors

! ',,	B Model	Wattage	Voltage	Brand/Model	LED quantity	colors	Pixel
	GSMY-12RGB	12W	DC24V	EPISTAR 5050	48	RGB	8
	GSMY-24RGB	24W	DC24V	EPISTAR 5050	2*48	RGB	8

	I Model	Wattage	Voltage	Brand/Model	LED quantity	colors	Pixel
	GSMY-12RGBW	12W	DC24V	EPISTAR 5050	48	RGBW	8
	JDSJ-24RGBA	24W	DC24V	EPISTAR 5050	2*48	RGBA	8

pixels can be divided into 8 segments, 12 segments, 16 segments and 32 segments,according to the requiremen

Product Advantages of DMX Linear Bar Series (Betterway Hotspot Product Series )

Size is slim,Shape is smart ,Quality is stable .

One LED one pixel ,3 LEDS One pixel,6 LEDS one pixel or customzied .

High grayscale 65536(16 bit).

Seamless connection .

Voltage DC12V ,DC24V,DC36V,DC48V.

Detachable connector .

Various sizes are available .

Type :Single Color ;DMX Single color 'DMX RGB;DMX RGBW.

Product Descriptions

1.Adopt high brightness SMD5050 which it's UV resistant ,Waterproof ,Dustproof .

2.The structure of this series can be seamless stitching .

3.The bar shell can be sprayed with the requirement color to fit the project .

4.Back side has trunking,cables can be hidden,to reduce the cable aging and extra tibet wire cost .

5.Surface with special material ,strong anti-yellowing properties ,hardy till minus 40℃.

6.Can live working ,resistant hot swappable .

7.constant current design .

8.Diversification installation .

9.Fully support color fading ,skipping ,scanning ,chasing ,play flash and vedio to music ,etc..

10.Compatible with MADRIX and BW software and other softwares .

11.Length:0.5M,1M,1.5M,2M or customized .

12.Energy-saving ,Low-cost maintenance ,Long-life span .

Applications

It is a perfect product for Entertainment and Architecture lighting such as Big TV Show ,Music Festival ,Stage Design ,Disco Clubs ,Outline of building and bridge ,Display screen and son on .
